采用国产飞腾D2000八核处理器，X100 GPU，支持DDR4内存，2*千兆网口，3*SATA，7*USB3.2 Gen1，2*PCIe x16，支持SIM
|
General |
|
|
CPU |
Phytium® D2000 Processor, 8-core, TDP 25W |
|
GPU |
Phytium® X100, LPDDR4 2GB |
|
Memory |
DDR4-3200, 2*U-DIMM, up to 32GB |
|
Storage |
3*SATA 3.0 1*M.2 (M-Key 2280, NVME SSD) |
|
Expansion |
1*M.2 (E-Key 2230, PCle + USB2.0), 2*PCle x16 1*PCle x4, 1*Mini-PCle (PCle + USB2.0), 1*SIM |
|
BIOS |
Byosoft BIOS |
| OS |
UOS, NeoKylin OS |
|
I/O |
|
|
Ethernet |
2*Motorcomm® GbE LAN |
|
Serial |
8*RS232 |
|
USB |
7*USB 3.2 Gen1, 4*USB 2.0 |
|
Audio |
Realtek HDA codec, with 1*Line-Out + MIC, 1*Line-Out, 1*MIC, 1*Line-in |
|
GPIO |
8*GPIO, 4*GPI+4*GPO |
|
Others |
1*SM Bus, 2*SPI, 2*CAN, 1*LPC |
|
Display |
|
|
Display Interface |
1*DP, 1*HDMI, 1*VGA |
|
Multiple Display |
Triple |
|
Mechanical & Environment |
|
|
Dimension |
244*244mm |
|
Power Input |
ATX PSU |
| Temperature |
Operation: 0℃~60℃ ,Storage: -20℃~75℃ |
|
Relative Humidity |
5%~95%, Non-condensing |
