SV1a-34524P

Intel Apollo Lake N3450处理器, 支持三屏异显, 2*LAN, 2*Mini-PCIe, DC 12V供电

采用Intel Apollo Lake N3450处理器
提供4*COM, 8*USB, 2*千兆LAN
提供1*VGA, 1*HDMI, 1*LVDS, 支持三屏异显
提供2*Mini-PCIe(支持mSATA, WiFi/3G/4G)
采用DC 12V供电
薄型Mini-ITX,板身厚度≤17mm
规格
General
CPU
Intel® Apollo Lake N3450 CPU, Quad-core, up to 2.2 GHz, TDP6W
Chipset
Null
Memory
Up to 8GB DDR3L 1866 MHz, 1*SO-DIMM
Storage
2*SATA 3.0, 1*mSATA
Expansion Interface
2*Mini-PCIe (1* mSATA Supported, 1*Wifi/3G/4G Supported)
BIOS
AMI UEFI BIOS
System
Windows 7/8/10, Linux
I/O Interface
Serial Port
4*RS232
USB
2*USB 3.0, 6*USB 2.0 (2*on rear I/O, 6*header)
Ethernet 2*Realtek® PCI-E LAN for 1000Mbps
Audio
Realtek® ALC662 5.1 channel HDA Codec, supports MIC/Line-outPorts
PS/2
1*PS/2 (Keyboard and Mouse Supported)
Parallel Port
1*LPT
GPIO
8 programmable GPIO
Feature Interface
Null
Display
Display Interface

1*VGA: max resolution up to 1920*1200

1*HDMI:max resolution up to 4096*2160

1*LVDS/eDP : DualChannel 24bit, max resolution up to 1920*1200;

eDP max resolution up to 1920*1080

Multiple Display
Triple
Mechanical & Environment
Dimension
Mini-ITX, 170*170mm
Power Input
DC 12V
Temperature Operation: 0℃~60℃, Storage: -25℃~75℃
Relative Humidity
Operation: 10%~90%, Storage: 5%~95%, non-condensing
